Application scenarios
1. Meat processing (ham, sausage, frozen meat chunks) - detecting metal fragments, bone fragments.
2. Aquatic seafood (fish balls, shrimp, shellfish) - remove shells, fish bones, and metal pollutants.
3. Dairy products (milk powder, cheese, liquid milk) - detect foreign objects in glass, plastic, and rubber.
4. Baked goods (bread, cookies, cakes) - Found metal wires, stones, hard plastics.
5. Quick frozen food (dumplings, rice dumpling, prepared dishes) - ensure no metal and glass are mixed in.
6. Condiments (sauces, powders, granules) - prevent foreign matter contamination and ensure food safety.
Features
1. Ultra high detection accuracy ensures no missed detections
Detection sensitivity: 0.3mm (metal ball)/0.2 * 2mm (metal wire)/0.6mm (ceramic, stone)/0.8mm (glass) (based on Finnish DT detector super-resolution).
Intelligent image processing: AI deep learning algorithms automatically recognize foreign objects, reducing manual misjudgment and achieving a detection
rate of ≥ 99.9%.
Adapt to complex products: can penetrate high-density packaging (such as cans, frozen foods, sauces, etc.), with clear and interference free imaging.
2. Efficient detection speed, matched with high-speed production lines
Detection speed: 20-75 meters/minute (adjustable, suitable for different production needs).
By size: 500mm (width) x 300mm (height), compatible with multiple packaging specifications (boxed, bagged, bottled, canned, etc.).
Seamless integration production line: supports automatic removal devices (air blowing/push rod), real-time sorting of non-conforming products, ensuring
production continuity.
3. Top international hardware, stable and durable
X-ray light source: VJ (Weijie) 210W high-frequency high-voltage generator from the United States, with strong penetration, stable imaging, and a service life
of ≥ 20000 hours.
Detector: Finnish DT 0.2mm high-precision linear array detector, with a wide dynamic range and strong anti-interference ability.
Protective safety: Fully enclosed lead curtain+multiple radiation protection design, leakage rate<1 μ Sv/h (far below national standards), in compliance with
GB/T 26148-2023 safety specifications.
4. Intelligent software, easy to operate
17 inch full-color touch screen, visual operation interface, supports multi language switching (Chinese/English/Japanese/Korean, etc.).
Data traceability system: automatically records detection data, generates PDF/Excel reports, supports USB drive export or cloud storage.
Remote monitoring: Optional Internet of Things (IoT) module for real-time monitoring of device status and remote fault diagnosis.
Technical Specifications
| Project | Parameter |
| Model | SPX-100 |
| Detection accuracy | 0.3mm (metal ball)/0.2 * 2mm (metal wire)/0.6mm (ceramic, stone)/0.8mm (glass) |
| Channel size | 500mm (width) × 300mm (height) |
| Detection speed | 20-75 meters/minute (adjustable) |
| X-ray light source | VJ 210W 80KV from the United States |
| Detector | Finnish DT X-Scan C 0.2mm linear array detector |
| Protection standards | Radiation leakage<1 μ Sv/h (compliant with national standards) |
| Software system | AI intelligent recognition+data tracing |
| Operating system | Windows 11 |
| Conveying weight | 20KG |
| Display screen | 17 inch full-color touch screen |
| Whole machine material | 304 stainless steel |
| Light source temperature adjustment | Industrial air conditioning automatic constant temperature/air cooling |
| Operation method | Touch screen operation |
| Support data interface | LAN port，USB port |
| Product Management | Complete product log |
| Parameter adjustment | Self learning/manual learning optional |
| Image management | Image saving/printing/analysis |
| Body material | SUS304 |
| Protection method | Detachable protective curtain/cover |
| Environmental temperature/humidity | 0~40 ° C/30~90%, no frost formation |
| Protection level | IP65 |
| Belt direction | Available from left to right/right to left |
| Elimination method | Swing rod/push plate removal/flipping/blowing air (optional) |
| Belt to ground height | 750+100mm (height can be customized and matched according to the assembly line) |
| Overall dimensions of the equipment | Length x width x height: 1650x530x1895 mm |
| Power requirements | AC 110-220V, 50/60Hz (customizable) |
Why choose our equipment?
1. Imported core components (US VJ light source+Finnish DT detector), with performance far exceeding similar domestic equipment.
High speed detection at 2.20-75 meters per minute, meeting the needs of large-scale production and increasing production capacity by 30%.
3. AI intelligent algorithms reduce false alarms and lower the cost of manual re inspection.
4. Modular design, easy maintenance, key components (light source, detector).
5. Free technical training+lifelong after-sales support to ensure long-term stable operation of the equipment.
Service and Support
1. Free on-site testing - providing sample testing services to verify equipment performance.
2. Customized solution - adjust equipment size, speed, and removal method according to production line requirements.
3.24-hour response - a professional technical team provides remote or on-site services.
