Product features:
1. Online PCBA AOI after the furnace.
2. High inspection rate, low false alarm rate, automatic inspection of color ring resistors, capacitors, diodes, sockets, etc.
3. Cross installation without changing the production line.
4. Simplified programming process, very simple interface. Support one click batch modification of parameters.
5. Centralized control. Interconnection between multiple devices.
6. Real time inspection without stopping the machine.
7. Easy to move, adjustable height and width.
8. Quickly locate defects and control the production line.
9. Data traceability. Support SPC alarm, LOG automatic collection and storage function, NG warning/alarm function, remote programming&debugging.
Product parameters:
| Technology Platform | Dual-track Type-c Platform |
| Series | A Series |
| Model | AI510DL |
| Measurement Principle | Sine white projectionPMP inspection |
| Measurements | Missing parts,offset,rotation,three-dimensional polarity, upside down, OCV, side standing, tombstone,poor soldering, etc. |
| Detection of Non-Performing Types | Solder tip, solder volume percentage,excessive solder, insufficient solder, bridge, hole plugging, solder filet, pad contamination, etc. |
| Lens Resolution | 6.5M 13.5μm/16.5μm option; 12M 12μm/15μm option |
| Accuracy | XY(Resolution):10um |
| Repeatability | height: ≤1μm (4 Sigma);volume/area: <1% (4 Sigma) |
| Gage R&R | <<10% |
| Inspection Speed | 0.45 SEC/FOV |
| Quanlity of Inspection Head | 4 pcs |
| Mark-point Detection Time | 0.5sec/piece |
| Maximun Meauring Head | 15mm |
| Maximum height ofelementon PCB | 40mm |
| Maximun Measuring Height ofPCB Warp | ±5mm |
| Minimum element | 01005 |
| Maximun Loading PCB & Detection Size(X*Y) | 450x310+450x310mm 600x310+600x310mm |
| Conveyor Setup | front orbit (back orbit as option) |
| PCB Transfer Direction | Left to right or Right to left |
| Conveyor Width Adjustment | manual & automatic |
| Engineering Statistics | SPC:Production Trend;Xbar-R Chart;Xbar-SChart;CP&CPK; %Gage Repartability Data;AOI Daily/ Weekly/Monthly Reports |
| Gerber & CAD Data Import | Support Gerber format (274x,274d),Artificial called the pattern, X/Yimport CAD |
| Operating System Support | Windows 10 Professional(64 bit) |
| Equipment Diemension and Weight | W1000xD1350xH1550mm,1200Kg |
| Optional | 1 D/2 D Barcode Scanner;Badmark Function; three-point function; offline programming; Repair Station |
